Overview
What this product is built to monitor
Highlight Features
- High Performance Hardware Platform features ARM Cortex-A8 CPU up to 1G Hz and up to 512MB Memory
- Bluetooth® 5.0 Technology
- Built to have Data tie into Pyxis Cloud™ Data Management Platform
- Data ties into any Cloud-Based Data Software
- LTE Cat 4 Module Optimized for M2M and IoT Applications, Major Carriers Supported (AT&T, Verizon and T-Mobile)
- WiFi Connectivity, Support IEEE 802.11 b/g/n Radio, Bit Rates up to 72.2Mbps (On-Debugging)
- Intuitive Web Interface for System Commissioning & Configuration
- Rugged Design to Work in Industrial Environments
Specifications
Key technical details
| Item | CloudLink™ |
| Part Number | 43030 |
| CPU | ARM Cortex A-8 32-bit Processor |
| Memory | up to 512MB |
| Storage | 4GB, up to 68GB Support |
| Ethernet Port | (1) RJ-45 (10/100 Base-T) |
| Serial Port | (1) RS-485 with 24V Output |
| Slim Slot | x1 |
| Micro SD Slot | x1 |
| Micro USB | x1 (For Configuration) |
| DC Power Input | 9-36VDC |
| Power Consumption | 3.6W |
| Antenna Connector | 1×50Ω SMA (Center Pin: Female) |
| On Board RTC | YES |
| LTE Category | 4G |
| Bands Supported | B1/2/3/4/5/6/7/12/13/14/20/28/66/71 |
| Carriers Supported | AT&T, Verizon, T-Mobile |
| Protocols Supported | IP/TCP/UDP/HTTP/HTTPS/Modbus |
| WiFi Connectivity | IEEE 802.11 b/g/n radio |
| Dimension | L 102mm, W 106mm, H 40mm |
| Weight | 300g |
| Storage Temperature Range | -12-158 °F (-25-70 °C) |
| Operation Temperature Range | -4-140 °F (-20-60 °C) |
| Humidity | 5-95% (No Condensation) |
| Environmental | IP30 |
