The LSP-Series are pressure based submersible level sen-sors offered in 316L (LSP-100 & LSP-101), PVC (LSP-200 &LSP-201) and PVDF (LSP-300 & LSP-301) formats for a vari-ety of liquid level applications. All LSP-Series sensors pro-vide continuous level measurement up to 393in (32.8ft or10m) with a 4–20mA analog and Bluetooth® digital output.They can easily be configured using the uPyxis® mobile &desktop app. Configure these devices in less than a minute with simple entry of tank liquid volume and specific gravity. This level sensor platform does not require liquid in the tank for configuration.

The LSP-100/200/300 devices offer a local display and can record up to 6 months of inventory data for wireless transfer via uPyxis® to email. The sensors can be powered by (4)AA Li/SOCl2 batteries or a 24VDC external power supply.These level sensors are ideally suited for applications where signal/power wiring may be difficult or unavailable. A 1.3inOLED display and four push-buttons are also included on the sensor for local display of level data and unit setup.

The LSP-101/201/301 devices use a 24VDC power supply only eliminating the battery compartment and local dis-play/data storage, providing a 4–20mA output signal to any receiving device. This platform offers a lower cost alterna-tive with superior accuracy and the convenience of rapidBluetooth® configuration.All LSP-Series submersible liquid level sensors are well suited for water, waste water, oil and chemical tank applications. The LSP Series of level sensors may be installed in the top-of-tank format or with the LSP Series Wall MountingBracket for easier access and visibility
